HDMI 2.0 2-Way Splitter (1-in/2-out) 4K at 60Hz

Name: HDMI 2.0 2-Way Splitter (1-in/2-out) 4K at 60Hz
Brand: Primus Cable
SKU: AV8-4265SP2
Price: 55.0 USD
Availability: InStock

by Primus Cable

$55.00

SKU: AV8-4265SP2

Quantity

Various lead times may apply to this product. Please contact us for more details.

Description

HDMI 2-Way Splitter (1-in/2-out) 4K at 60Hz

Our 1x2 HDMI Splitter distributes the input of the HDMI signal into 2 identical outputs simultaneously. Supporting 4K at 60Hz, the splitter will assure you amazing picture quality four times the resolution of 1080p at 60Hz. Even though it is a 4K HDMI Splitter, it is backward compatible with older revisions such as 108p/720p. Perhaps you are wanting to display a game on multiple TVs at a family event. Using this HDMI Splitter allows you to display the game on multiple devices coming from a single source (cable box, satellite box, blu ray player).

Features

1-in / 2-out HDMI splitter
No need to set up, plug, and play
Supports HDMI 3D 4K x 2K at 60Hz (Standard HDMI High Speed with Ethernet 28AWG cable)
Backward compatible with 720p and 1080p
Works with HDMI or DVID, HDCP-enabled HDTV
EDID Supported
Bandwidth up to 18Gbps
Support HDCP 2.2 and HDCP 1.4
Metal casing design and over all shielding without signal interference
LED light indicates signal and power mode
Supports audio formats: DTS-HD / Dolby-TrueHD / LPCM7.1 / DTS / Dolbt-AC3 and DSD
RoHs compliant

Applications:

Specifications

Specifications:

HDMI Source Input Port	1
Display Device Output Ports	2
Source Port Connector	19 Pin HDMI
Display Port Connector	19 Pin HDMI
HDCP Compliant	Yes
Single Link Range	3840*2160
Input Video Signal	0.5-1.0 Volts P-P
Input DDC Signal	5 Volts P-P(TTL)
Deep Color	36 Bit
HDMI Version	HDMI 2.0
Bandwidth	Up to 600MHz
Signal Speed	Up to 18Gbps
Weight	0.761lbs.
Cable Standard	26AWG HDMI 2.0
Vertical Frequency Range	60Hz
Power Consumption	2.5 Watts Maximum
Operation Temperature	0C-70°C
Working Voltage	DC 5 Volts
Power Adaptor	5V 1A
Dimensions	Length = 19" (482mm) Width = 14.5" (368mm) Height = 6" (152mm)

Additional Information

To learn more about our Amplifiers and Splitters here is a link to a page containing more information on our premium Amplifiers and Splitters.

For more info on HDMI, see below.

HDMI Type	Max Resolution	Transmission Rate	HDR	Audio Support
1.4	4K x 2K at 30Hz	10.2 Gb/s	No	ARC, Dolby TrueHD, DTS-HD
2.0	4K at 60Hz	18 Gb/s	Yes	HE-AAC, DRA, 32 audio channels
2.1	8K at 30Hz	48 Gb/s	Yes	eARC

What's in the Box?
