SFP Fiber Transceiver Modules, Single Mode, 20KM 1000BASE-BX10-D WDM Bi-Directional, LC Connector, TX-1490/RX-1310, Cisco Compatible

Comparable to Cisco's GLC-BX-D and compatible with Cisco switches.

Description

SFP Fiber Transceiver Modules, 1000BASE-BX10-D WDM Bi-Directional, TX1490nm/RX1310nm SMF, up to 20 Kilometers, LC, Cisco Compatible

The industry-standard Small Form-Factor Pluggable (SFP) Gigabit Interface Converter is a hot-swappable input/output device that plugs into a Gigabit Ethernet port or slot, linking the port with the network. SFPs can be used and interchanged on a wide variety of media converters and ethernet switches.

The TRC-4688-GLCD and TRC-4687-GLCU SFPs, compatible with the IEEE 802.3ah TRC-4688-GLCD and TRC-4687-GLCU standards, operate on a single strand of standard SMF.

A TRC-4688-GLCD device is always connected to a TRC-4687-GLCU device with a single strand of standard SMF with an operating transmission range up to 20 km.

The communication over a single strand of fiber is achieved by separating the transmission wavelength of the two devices: TRC-4688-GLCD transmits a 1490-nm channel and receives a 1310-nm signal, whereas TRC-4687-GLCU transmits at a 1310-nm wavelength and receives a 1490-nm signal. There is a wavelength-division multiplexing (WDM) splitter integrated into the SFP to split the 1310-nm and 1490-nm light paths.

The TRC-4688-GLCD and TRC-4687-GLCU SFPs also support digital optical monitoring (DOM) functions according to the industry-standard SFF-8472 multisource agreement (MSA). This feature gives the end user the ability to monitor real-time parameters of the SFP, such as optical output power, optical input power, temperature, laser bias current, and transceiver supply voltage.

Specifications

Cisco Compatibility Chart

Metro Ethernet

• ME-2400-24TS-A
• ME-2400-24TS-D
• ME2600X-44FA-D-K9=
• ME2600X-44FE-D-K9=
• ME2600X-44FA-A-K9=
• ME-3400-24TS-A
• ME-3400-24TS-D
• ME-3400G-12CS-A
• ME-3400G-12CS-D
• ME-3400G-2CS-A
• ME-3400-24FS-A
• ME-3400E-24TS-M
• ME-3400EG-2CS-A
• ME-3400EG-12CS-M
• ME-C3750-24TE-M
• ME-3600X-24FS-M¹
• ME-3600X-24CX-M
• ME-3800X-24FS-M²
• ME4600-AMX-48GE
• ME-4924-10GE
• ME-C6524GS-8S
• ME-C6524GT-8S

Catalyst 2900 Series

• WS-C2960-24TC-L
• WS-C2960G-24TC-L
• WS-C2960-48TC-L
• WS-C2960-24PC-L
• WS-C2960-48PST-L
• WS-C2960-8TC-L
• WS-C2960G-8TC-L
• WS-C2960G-48TC-L
• WS-C2960+48PST-L
• WS-C2960+24PC-L
• WS-C2960+24LC-L
• WS-C2960+48TC-L
• WS-C2960+24TC-L
• WS-C2960S-48FPS-L
• WS-C2960S-48LPS-L
• WS-C2960S-24PS-L
• WS-C2960S-48TS-L
• WS-C2960S-24TS-L
• WS-C2960S-48FPD-L
• WS-C2960S-48LPD-L
• WS-C2960S-24PD-L
• WS-C2960S-48TD-L
• WS-C2960S-24TD-L
• 2960S-F48FPS-L
• 2960S-F48LPS-L
• 2960S-F24PS-L
• 2960S-F48TS-L
• 2960S-F24TS-L
• WS-C2960CG-8TC-L
• WS-C2960C-8TC-L
• WS-C2960C-8PC-L
• WS-C2960C-12PC-L
• WS-C2960X-24PSQ-L
• WS-C2960X-24PS-L
• WS-C2960X-24TS-L
• WS-C2960X-48TS-L
• WS-C2960X-48LPS-L
• WS-C2960X-48FPS-L
• WS-C2960X-24TD-L
• WS-C2960X-24PD-L
• WS-C2960X-48TD-L
• WS-C2960X-48LPD-L
• WS-C2960X-48FPD-L
• WS-C2960XR-24TS-I
• WS-C2960XR-48TS-I
• WS-C2960XR-24PS-I
• WS-C2960XR-48LPS-I
• WS-C2960XR-48FPS-I
• WS-C2960XR-24TD-I
• WS-C2960XR-48TD-I
• WS-C2960XR-24PD-I
• WS-C2960XR-48LPD-I
• WS-C2960XR-48FPD-I

Catalyst 3500 Series

• WS-C3560-24PS
• WS-C3560-48PS
• WS-C3560G-24TS
• WS-C3560G-48TS
• WS-C3560G-48PS
• WS-C3560G-24PS
• WS-C3560-48TS
• WS-C3560-24TS
• WS-C3560-8PC
• WS-C3560-12PC-S
• WS-C3560V2-24PS
• WS-C3560V2-24TS
• WS-C3560V2-48PS
• WS-C3560V2-48TS
• WS-C3560E-24TD⁴
• WS-C3560E-24PD⁴
• WS-C3560E-48TD⁴
• WS-C3560E-48PD⁴
• WS-C3560E-48PDF⁴
• WS-C3560E-12D⁴
• WS-C3560E-12SD
• WS-C3560E-12SD⁴
• WS-C3560X-24T⁵
• WS-C3560X-48T⁵
• WS-C3560X-24P⁵
• WS-C3560X-48P⁵
• WS-C3560X-48PF⁵
• WS-C3560X-24T⁶
• WS-C3560X-48T⁶
• WS-C3560X-24P⁶
• WS-C3560X-48P⁶
• WS-C3560X-48PF⁶
• WS-C3560CG-8TC-S
• WS-C3560CG-8PC-S
• WS-C3560C-8PC-S
• WS-C3560C-12PC-S

Catalyst 3600 Series

• WS-C3650-24TS
• WS-C3650-48TS
• WS-C3650-24PS
• WS-C3650-48PS
• WS-C3650-48FS
• WS-C3650-24TD
• WS-C3650-48TD
• WS-C3650-24PD
• WS-C3650-48PD
• WS-C3650-48FD
• WS-C3650-48FQ
• WS-C3650-48PQ
• WS-C3650-48TQ

Catalyst 3700 Series

• WS-C3750G-12S
• WS-C3750G-24TS
• WS-C3750G-48TS
• WS-C3750G-24PS
• WS-C3750G-48PS
• WS-C3750-24TS
• WS-C3750-48TS
• WS-C3750-24PS
• WS-C3750-48PS
• WS-C3750-24FS-S
• WS-C3750-24WFS
• WS-C3750V2-24PS³
• WS-C3750V2-24TS³
• WS-C3750V2-48PS³
• WS-C3750V2-48TS³
• WS-C3750V2-24FS³
• WS-C3750E-24TD⁴
• WS-C3750E-24PD⁴
• WS-C3750E-48TD⁴
• WS-C3750E-48PD⁴
• WS-C3750E-48PDF⁴
• WS-C3750X-24T⁵
• WS-C3750X-48T⁵
• WS-C3750X-24P⁵
• WS-C3750X-48P⁵
• WS-C3750X-48PF⁵
• WS-C3750X-24T⁶
• WS-C3750X-48T⁶
• WS-C3750X-24P⁶
• WS-C3750X-48P⁶
• WS-C3750X-48PF⁶
• WS-C3750X-12S⁷
• WS-C3750X-24S⁷
• WS-C3750X-12S⁸
• WS-C3750X-24S⁸

Catalyst 3800 Series

• C3850-NM-4-1G
• C3850-NM-2-10G
• C3850-NM-4-10G

Industrial Ethernet and Smart Grid

• IE-2000-4TS-G-L
• IE-2000-4TS-G-B
• IE-2000-4T-G-L
• IE-2000-4T-G-B
• IE-2000-8TC-G-L
• IE-2000-8TC-G-B
• IE-2000-8TC-G-E
• IE-2000-8TC-G-N
• IE-2000-16TC-G-L
• IE-2000-16TC-G-E
• IE-2000-16TC-G-X
• IE-2000-16TC-G-N
• IE-2000-16PTC-G-L
• IE-2000-16PTC-G-E
• IE-2000-16PTC-G-NX
• IE 2000U-4TS-G
• IE 2000U-8TC-G
• IE 2000U-16TC-G
• IE 2000U-16TC-G-X
• IE 2000U-16TC-GP
• IE-3000-4TC
• IE-3000-8TC
• IE-3010-24TC
• IE-3010-16S-8PC
• CGS-2520-24TC
• CGS-2520-16S-8PC

Catalyst 4500 Series

• WS-X4013+TS
• WS-X4013+10GE
• WS-X4748-SFP-E
• WS-X4724-SFP-E
• WS-X4712-SFP-E
• WS-X4448-GB-SFP
• WS-X4506-GB-T
• WS-X4516-10GE
• WS-X45-SUP6-E⁹
• WS-X4606-X2⁹
• WS-X4624-SFP-E
• WS-X45-SUP6L-E⁹
• WS-X4612-SFP-E
• WS-X4640-CSFP-E
• WS-X4712-SFP+E
• WS-X45-SUP7-E
• WS-X45-SUP7L-E
• WS-X45-SUP8-E
• WS-C4500X-32SFP+
• WS-C4500X-F-32SFP+
• WS-C4500X-40X-ES
• C4KX-NM-8SFP+
• WS-C4500X-16SFP+
• WS-C4500X-F-16SFP+
• WS-C4500X-24X-ES

Catalyst 4900 Series

• WS-C4948
• WS-4928-10GE
• WS-C4948E
• WS-X4908¹⁰

Catalyst 6500 Series

• WS-SUP720
• WS-SUP720-3B
• WS-SUP720-3BXL
• WS-SUP32-GE-3B
• WS-SUP32-10GE-3B
• WS-SUP32-GE-PISA
• VS-S720-10G-3C
• VS-S720-10G-3CXL
• WS-X6724-SFP
• WS-X6748-SFP
• VS-S2T-10G
• VS-S2T-10G-XL
• WS-X6824-SFP-2T
• WS-X6824-SFP-2TXL
• WS-X6848-SFP-2T
• WS-X6848-SFP-2TXL
• WS-X6904-40G-2T
• WS-X6904-40G-2TXL

Catalyst 6800 Series

• C6800IA-48FPD
• C6800IA-48TD

Data Center and Blade Switching

• N7K-M148GS-11
• N7K-M148GS-11L
• N7K-F248XP-25
• N7K-F248XP-25E
• N77-F348XP-23

Routers

• CISCO892F-K9
• CISCO892FW-K9
• EHWIC-1GE-SFP-CU
• Cisco 2921
• Cisco 2951
• SM-D-ES3G-48-P
• SM-D-ES3-48-P
• SM-D-ES2-48
• Cisco 3925
• Cisco 3945
• Cisco 4451-X
• 7300-NSE-150
• WS-SUP32-GE-3B
• WS-X6724-SFP
• WS-X6748-SFP
• RSP720-3C-GE
• RSP720-3CXL-GE
• RSP720-10GE
• 7600-ES20-GE3CXL
• 7600-ES20-GE3C
• 7600-ES+20G3C
• 7600-ES+20G3CXL
• 7600-ES+40G3C
• 7600-ES+40G3CXL
• 76-ES+T-20G
• 76-ES+T-40G
• 76-ES+XC-20G3C
• 76-ES+XC-20G3CXL
• 76-ES+XC-40G3C
• 76-ES+XC-40G3CXL
• A901-12C-F-D
• A901-12-C-FT-D
• A901-4C-F-D
• A901-4-C-FT-D
• A901-6CZ-F-D
• A901-6-CZ-FT-D
• A901-6CZ-F-A
• A901-6-CZ-FT-A
• A900-IMA8S
• ASR1001
• ASR1002
• ASR1002-F
• ASR1002-X
• A9K-40GE-B
• A9K-40GE-E
• A9K-2T20GE-B
• A9K-2T20GE-E
• A9K-2T20GE-L
• A9K-40GE-L
• A9K-MPA-20X1GE
• A9K-RSP440-TR
• A9K-RSP440-SE
• ASR-9000V-AC
• ASR-9000V-DC-A
• ASR-9000V-DC-E
• MWR-2941-DC

LAN Controllers

• AIR-CT5760-25-K9
• AIR-CT5760-50-K9
• AIR-CT5760-100-K9
• AIR-CT5760-250-K9
• AIR-CT5760-500-K9
• AIR-CT5760-1K-K9
• AIR-CT5760-HA-K9
