SG2008 TP-Link|Omada JetStream 8-Port Gigabit Smart Ethernet Switch
Software Defined Networking (SDN) with Cloud Access
Omada’s Software Defined Networking (SDN) platform integrates network devices, including access points, switches and gateways, providing 100% centralized cloud management. Omada creates a highly scalable network—all controlled from a single interface. Seamless wireless and wired connections are provided, ideal for use in hospitality, education, retail, offices, and more.
Features
Features
- Full Gigabit Ports: 8× gigabit RJ45 ports provide high-speed connections.
- Integrated into Omada SDN: Zero-Touch Provisioning (ZTP)*, Centralized Cloud Management, and Intelligent Monitoring.
- Centralized Management: Cloud access and Omada app for ultra convenience and easy management.
- Robust Security Strategies: 802.1Q VLAN, ACL, Port Security, Storm Control, and more.
- Optimize Voice and Video Applications: L2/L3/L4 QoS and IGMP snooping.
- Versatile Management: WEB/CLI managed modes, SNMP, and RMON bring abundant management features.
Specifications
Specifications
| HARDWARE FEATURES | ||
|---|---|---|
| Interface | 8 x 10/100/1000 Mbps RJ45 Ports, Auto-Negotiation/Auto MDI/MDIX | |
| Fan Quantity | Fanless | |
| Power Supply | 12 VDC/1 A External Adapter or Power from PoE source | |
| Dimensions (W x D x H) | 8.2 x 4.9 x 1.0 in (209 x 126 x 26mm) | |
| Max Power Consumption | 6.4 W (220 V/50 Hz) | |
| PERFORMANCE | ||
|---|---|---|
| Bandwidth/Backplane | 16 Gbps | |
| Packet Forwarding Rate | 11.9 Mpps | |
| MAC Address Table | 8 K | |
| Packet Buffer Memory | 4.1 Mbit | |
| Jumbo Frame | 9 KB | |
| GENERAL | ||
|---|---|---|
| Certification | FCC, CE, RoHS | |
| Package Contents | SG2008 Power Adapter Installation Guide Rubber Feet | |
| System Requirements | Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7, MAC® OS, NetWare®, UNIX® or Linux. | |
| Environment | Operating Temperature: 0℃~40℃ (32℉~104℉) Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing | |
Additional Information
Ethernet Switch Accessories
An Ethernet network switch is a telecommunication device that receives data transmitted from a connected device and relays it to a specific device. Ethernet switches create separate collision domains per switch port, allowing for simultaneous data transfers to occur without interference. They also reduce the number of broadcast domains, and don't require heavy CPU usage. The Ethernet switch manages the flow of network traffic more efficiently and in a safer manner than repeater hubs. It allows for the flow of data between connected devices. Ethernet switches come in both managed and unmanaged varieties. Unmanaged switches are the easy to install, plug and play variety. To learn more about our switches please visit our overview page. Our Switches can be combined with a wide array of products.
What's In The Box
What's In The Box
- Qty 1 - SG2008
- Qty 1 - Power Cord
- Qty 1 - Installation Guide
- Qty 1 - Resource CD
- Qty 4 - Rubber Feet
