Description
5-Port Gigabit Easy Smart Switch
What This Product Does
The TP-Link 5-Port 10/100/1000Mbps Desktop Switch provides you an easy way to make the transition to Gigabit Ethernet. Increase the speed of your network server and backbone connections, or make Gigabit to the desktop a reality. Plug and Play design, with no configuration required, makes the product easy to use. Moreover, TL-SG105S adopts lower power consumption design. With the innovative energy-efficient technology, the TL-SG105S can save power consumption, making it an eco-friendly solution for your home or office network.
Gigabit Switch
Featured with 5 10/100/1000Mbps ports, TL-SG105S greatly expands your network capacity, enabling instant large files transferring. So, power users in the home, office, workgroup, or creative production environment can now move large, bandwidth-intensive files faster. Transfer graphics, CGI, CAD, or multimedia files across the network instantly.
Go Green With Your Ethernet
You now have the choice to go green when upgrading to a gigabit network! This new generation TL-SG105S 5-Port 10/100/1000Mbps Desktop Switch features the latest innovative energy-efficient technologies that can greatly expand your network capacity with much less power. It automatically adjusts power consumption according to the link status and cable length to limit the carbon footprint of your network.
Traffic Optimization
802.1p and DSCP QoS enable smooth latency-sensitive traffic such as voice and video, and IGMP Snooping optimizes the Multicast data stream.
Easy to use
The auto features of this gigabit switch make installation plug and play and hassle-free. No configuring is required. Auto MDI/MDIX eliminate the need for crossover cables. Auto-negotiation on each port senses the link speed of a network device (either 10, 100, or 1000 Mbps) and intelligently adjusts for compatibility and optimal performance. Moreover, fanless design ensures quiet operation.
Features
Features
- 5 10/100/1000Mbps Auto-Negotiation RJ45 ports with auto-MDI/MDIX
- Green Ethernet technology saves power
- IEEE 802.3x flow control provides reliable data transfer
- Metal housing, desktop or wall-mounting design
- Support 802.1p/DSCP QoS and IGMP Snooping
- Plug and play, with no configuration required
Specifications
Specifications
| HARDWARE FEATURES |
||
|---|---|---|
| Interface | 5 x 10/100/1000Mbps, Auto-Negotiation, Auto-MDI/MDIX Ports | |
| Fan Quantity | Fanless | |
| Power Consumption | 2.4W | |
| External Power Supply | External Power Adapter (Output: 9VDC / 0.6A) | |
| LED Indicator |
System Power Link/Act Indicators per port built into each RJ45 Port |
|
| Dimensions (W x D x H) |
3.9 x 3.9 x 1.0 in (100 x 98 x 25mm) |
|
| PERFORMANCE | ||
|---|---|---|
| Packet Forwarding Rate | 7.4 Mpps |
|
| MAC Address Table | 2 K |
|
| Packet Buffer Memory | 1 Mb |
|
| Jumbo Frame | 16 KB |
|
| GENERAL | ||
|---|---|---|
| Certification |
FCC, RoHS |
|
| Package Contents |
5-Port 10/100/1000 Mbps Desktop Switch Power Adapter Installation Guide Rubber Feet |
|
| Environment |
Operating Temperature: 0°C~40°C (32°F~104°F) Storage Temperature: -40°C~70°C (-40°F~158°F) Operating Humidity: 10% ~ 90% non-condensing Storage Humidity: 5%~90% non-condensing |
|
Additional Information
Ethernet Switch Accessories
An Ethernet network switch is a telecommunication device that receives data transmitted from a connected device and relays it to a specific device. Ethernet switches create separate collision domains per switch port, allowing for simultaneous data transfers to occur without interference. They also reduce the number of broadcast domains, and don't require heavy CPU usage. The Ethernet switch manages the flow of network traffic more efficiently and in a safer manner than repeater hubs. It allows for the flow of data between connected devices. Ethernet switches come in both managed and unmanaged varieties. Unmanaged switches are the easy to install, plug and play variety. To learn more about our Ethernet Switches please visit our overview page. These Switches can be combined with a wide array of products such as:
- CAT6 Ethernet Cables
- CAT6A Ethernet Cables
- CAT5E Ethernet Cables
- PoE Splitter, Fast Ethernet, 1 Port
What's In The Box
What's In The Box
- Qty 1 - TL-SG105S
- Qty 1 - Power Adapter
- Qty 1 - Installation Guide
- Qty 4 - Rubber Feet
